Features:
10 AMP Plug
AC/DC H/F TIG & PULSE TIG
Pre Gas 0.1
3.0 sec - Start Amperage 10
180A - Up Slope 0
10 sec - Peak Amp 10
180A - AC Square Wave 20
250Hz - AC Balance Control ±10
Down Slope 0 - 15 sec
Adjustable Finish Amperage 10 - 180A
Post Gas 0.5 - 15.0 sec
STICK (MMA) with ARC FORCE
Thermal overload protection
IP21S rating for environmental/safety protection
Generator compatible (recommend KVA minimum)
VRD (Voltage Reduction Device)
Foot Control Ready
Welds:
Aluminium
Magnesium
Zinc Alloys
Steels
Stainless
Cast Iron
Bronze
Copper
TIG Specifications:
TIG Function Type: AC/DC H/F TIG & AC/DC Pulse
TIG Welding Current Range: 10-180A
TIG Duty Cycle 40°C: 15% 180A
TIG Welding Thickness Range: 1mm - 6mm
AC/DC Tig Parameters:
Pre Gas: 0.1-3.0s
Start AMP: 10-180A
UP Slope: 0-10s
Peak AMP: 10-180A
AC Square Wave: 20-250Hz
AC Balance Control: ±10
Down Slope: 0-15s
Finish AMP: 10-180A
Post Gas: 0.5-15.0s
Pulse Frequency: 0.2-200Hz
Pulse Width: 10-90%
Spot: 0.5-10s
Stick Specifications:
Stick Welding Current Range: 10-130A
Stick Duty Cycle: 10% @ 130A
Arc Force: 0-40
Stick Electrode Range: 2.5-3.2mm
Stick Welding Thickness: 2mm - 10mm
Specifications:
Voltage: 240V Single Phase
Supply Plug: 10 AMP
Rated Input Power: 5.2kVA
Left (A): 8.9
Imax (A): 23.0
Rated Output: 10-180A / 17.2V
No Load Voltage:
Min: 7V
Max: 55V
Protection Class IP21S
Insulation Class: B
Minimum Generator: 9kVA
Dinse Connector: 35/50
Standard: AS/NZ60974-1
Dimensions (L x H x W): 502mm x 218mm x 382mm
Weight: 12.8kg
